    • High Performance LED replacements for conventional T5 lamps

      24T5HO/COR/46-840/IF35/G/DIM 25/1
      LED
      24T5HO/COR/46-840/IF35/G/DIM 25/1
      T5

      24T5HO/COR/46-840/IF35/G/DIM 25/1

      Downloads

      Spec Sheet
      Size:905.9 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Power Factor (Fraction)
    0.9
    Line Frequency
    50 to 60 Hz
    Starting Time (Nom)
    0.5 s
    Power Consumption
    24 W
    Voltage (Nom)
    120-277, 347 V
    Warm-up time to 60% light
    0.5 s
    Input Frequency
    50 to 60 Hz
    Product Data
    Numerator - Quantity Per Pack
    1
    Net weight
    0.151 kg
    Order product name
    24T5HO/COR/46-840/IF35/G/DIM 25/1
    Numerator - Packs per outer box
    25
    EAN/UPC - Case
    50046677576733
    Order code
    576736
    Full product name
    24T5HO/COR/46-840/IF35/G/DIM 25/1
    Material number (12NC)
    929003134104
    Approval and Application
    Energy Saving Product
    Yes
    Approval Marks
    RoHS compliance
    UL certificate
    DLC compliance
    Controls and Dimming
    Dimmable
    Only with specific dimmers
    General Information
    Lighting Technology
    LED
    EU RoHS compliant
    Yes
    Brand
    Philips
    Cap-Base
    G5  [G5]
    Switching Cycle
    50,000
    Nominal lifetime
    50,000 hour(s)
    Mechanical and Housing
    Bulb Material
    Glass
    Product Length
    1,200 mm
    Bulb Finish
    Frosted
    Bulb Shape
    Tube, double-ended
    Temperature
    Ambient temperature range
    -20 °C to 45 °C
    T-Case Maximum (Nom)
    70 °C
    Light Technical
    Color rendering index (CRI)
    80
    Color Designation
    Cool White (CW)
    Luminous Efficacy (rated) (Nom)
    145.00 lm/W
    Color Consistency
    <6
    Beam Angle (Nom)
    200 degree(s)
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Luminous Flux
    3,500 lumen
    Correlated Color Temperature (Nom)
    4000 K
    Color Code
    840  [CCT of 4000K]

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     G5 Tube, double-ended Frosted
    G5 Tube, double-ended Frosted
    G5
    G5
    Performance Diagrams
    Lumen Maintenance Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Lumen Maintenance Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Lumen Maintenance Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Lumen Maintenance Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Life Expectancy Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Life Expectancy Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Life Expectancy Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Life Expectancy Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Life Expectancy Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Life Expectancy Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Photometrics
    General uniform lighting
    General uniform lighting
    Spectral Power Distribution Colour - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Spectral Power Distribution Colour - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Light Distribution Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Light Distribution Diagram - 24T5HO/COR/46-840/IF35/G/DIM 25/1
    Downloads
    Leaflets
    Green Data
    Visuals
    Photometry/BIM Files
    • IES IES File - 24T5HO/COR/46-840/IF35/G/DIM 25/1 IES 124.6 kB
