    • Instant retrofit, instant savings

      63CC/LED/3CCT/LS EX39 G3 BB 3/1
      LED
      63CC/LED/3CCT/LS EX39 G3 BB 3/1
      LED Corn Cobs

      63CC/LED/3CCT/LS EX39 G3 BB 3/1

      Downloads

      Spec Sheet
      Size:1.7 MB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Power Factor (Fraction)
    0.9
    Starting Time (Nom)
    1 s
    Line Frequency
    50 to 60 Hz
    Power Consumption
    63 W
    Input Frequency
    50 to 60 Hz
    Voltage (Nom)
    100-277 V
    Warm-up time to 60% light
    1 s
    Lamp Current (Nom)
    700 mA
    Approval and Application
    EU RoHS compliant
    Yes
    Product Data
    Full product name
    63CC/LED/3CCT/LS EX39 G3 BB 3/1
    Numerator - Quantity Per Pack
    1
    Order product name
    63CC/LED/3CCT/LS EX39 G3 BB 3/1
    Numerator - Packs per outer box
    3
    EAN/UPC - Case
    50046677570496
    Order code
    570499
    Material number (12NC)
    929003065504
    Controls and Dimming
    Dimmable
    Preset Dimming
    General Information
    Lighting Technology
    LED
    Cap-Base
    EX39  [Exclusionary Mogul Screw]
    Switching Cycle
    50,000
    Nominal lifetime
    50,000 hour(s)
    Mechanical and Housing
    Bulb Finish
    Clear
    Bulb Material
    Plastic
    Bulb Shape
    Corncob
    Temperature
    Ambient temperature range
    -20 °C to 45 °C
    T-Case Maximum (Nom)
    65 °C
    Light Technical
    Luminous Efficacy (rated) (Nom)
    124.00 lm/W
    Color Designation
    Daylight
    Color rendering index (CRI)
    80
    Color Consistency
    ANSI 5000K quadrangle
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Correlated Color Temperature (Nom)
    3000 K
    4000 K
    5000 K
    Color Code
    850  [CCT of 5000K]

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Exclusionary Mogul Screw Corncob Clear
    Exclusionary Mogul Screw Corncob Clear
    EX39
    EX39
    Performance Diagrams
    Lumen Maintenance Diagram - 63CC/LED/3CCT/LS EX39 G3 BB 3/1
    Lumen Maintenance Diagram - 63CC/LED/3CCT/LS EX39 G3 BB 3/1
    Life Expectancy Diagram - 63CC/LED/3CCT/LS EX39 G3 BB 3/1
    Life Expectancy Diagram - 63CC/LED/3CCT/LS EX39 G3 BB 3/1
    Photometrics
    General uniform lighting - 63CC/LED/3CCT/LS EX39 G3 BB 3/1
    General uniform lighting - 63CC/LED/3CCT/LS EX39 G3 BB 3/1
    Spectral Power Distribution Colour - 63CC/LED/3CCT/LS EX39 G3 BB 3/1
    Spectral Power Distribution Colour - 63CC/LED/3CCT/LS EX39 G3 BB 3/1
    Light Distribution Diagram - 63CC/LED/3CCT/LS EX39 G3 BB 3/1
    Light Distribution Diagram - 63CC/LED/3CCT/LS EX39 G3 BB 3/1
