2.7G16.5/PER/927-922/CL/G/E26/WGX 1FBT20

Specifications Show all

Operating and Electrical

Starting Time (Nom)	0.5 s
Wattage Equivalent	25 W
Power Consumption	2.7 W
Voltage (Nom)	120 V
Line Frequency	50 to 60 Hz
Warm-up time to 60% light	0.5 s
Lamp Current (Nom)	30 mA
Power Factor (Fraction)	0.75
Input Frequency	50 to 60 Hz

Approval and Application

Energy Consumption kWh/1000 h	- kWh
EU RoHS compliant	Yes
Energy Certifications	Energy Star

Product Data

Full product name	2.7G16.5/PER/927-922/CL/G/E26/WGX 1FBT20
Numerator - Quantity Per Pack	1
Order code	549253
EAN/UPC - Case	50046677549256
Material number (12NC)	929002204804
Order product name	2.7G16.5/PER/927-922/CL/G/E26/WGX 1FBT20
Numerator - Packs per outer box	10

Controls and Dimming

Dimmable

Yes

General Information

Cap-Base	E26  [Single Contact Medium Screw]
Rated Lifetime (Hours)	15,000 hour(s)
Switching Cycle	20,000
Nominal lifetime	15,000 hour(s)
Lighting Technology	LED

Mechanical and Housing

Bulb Material	Glass
Bulb Shape	G16.5  [G16.5]
Bulb Finish	Clear

Temperature

T-Case Maximum (Nom)

45 °C

Light Technical

Luminous Efficacy (rated) (Nom)	92.00 lm/W
Color Designation	Warm Glow(WG)
Color rendering index (CRI)	90
Color Consistency	<4
Luminous Flux	250 lumen
Correlated Color Temperature (Nom)	2700 K	2200 K
Color Code	927-922  [CCT of 2700K-2200K]
LLMF At End Of Nominal Lifetime (Nom)	70 %
